KFV BS-2800-U24-35-92-8 P 6/24 R001.
Lock case without the face plate see related products.
Art: 5700682
Center distance 92 mm.
Backset 35 mm.

KFV BS-2800-U24-35-92-8 P 6/24 R001.

Lock case without the face plate see related products.

Art: 5700682

Center distance 92 mm.

Backset 35 mm.

Face plate width U24 mm.



A = 2170 mm

B = 823 mm

C = 810 mm

F = 410 mm

G = 1020 mm

H = 260 mm

I = 260 mm

K = 137 mm

Dimensions when closed
