KFV BS-2800-F16-55-92-8 R001.
Art: Kfv 5700707.
Lock case without the face plate see related products.
Center distance 92 mm.
Backset 55 mm.

KFV BS-2800-F16-55-92-8 R001.

Art: Kfv 5700707.

Lock case without the face plate see related products.

Center distance 92 mm.

Backset 55 mm.

Face plate width F16 mm.

A = 2170 mm

B = 82.3 mm

C = 810 mm

F = 410 mm

G = 1020 mm

H = 260 mm

I = 260 mm

K = 137 mm

Dimensions when closed

Pdf-bs2800
