KFV BS-2800-F16-55-72-8 R016.
Art: Kfv 5700666.
Lock case without the face plate see related products.
Center distance 72 mm.
Backset 55 mm.

KFV BS-2800-F16-55-72-8 R016.

Art: Kfv 5700666.

Lock case without the face plate see related products.

Center distance 72 mm.

Backset 55 mm.

Face plate width F16 mm.

A = 2170 mm

B = 970 mm

C = 910 mm

F = 410 mm

G = 1042 mm

H = 260 mm

I = 138 mm

K = 0 mm

Dimensions when closed

Pdf-bs2800
