KFV AS-9800-U24-25-92-8 P 6/24.
Lock case without the face plate see related products.
Art:
Center distance 92 mm.
Backset 25 mm.

KFV AS-9800-U24-25-92-8 P 6/24.

Lock case without the face plate see related products.

Art:

Center distance 92 mm.

Backset 25 mm.

Face plate width U24 mm.



A = 2170 mm

B = 823 mm

C = 810 mm

F = 410 mm

G = 1020 mm

H = 260 mm
