Fuhr 855 F24-40/92/8
⚡︎ 420,473€ 263.06
Available
Fuhr 855GL F24-40/92/8.
Lock case without the face plate see related products.
Center distance 92 mm.
Backset 40 mm.
Face plate width F24 mm.
Fuhr 855GL F24-40/92/8.
Lock case without the face plate see related products.
Center distance 92 mm.
Backset 40 mm.
Face plate width F24 mm.
Front plate length 2400 mm.
Direction of rotation reversible.
Key operated
Distance from the center of the handle hole to the center of the lock
Down 762 mm.
Upwards 930 mm.
Lock dimensions 210x55x16 & 156x47x15 mm.
